Components marked with this symbol are safety critical
and should only be replaced with identical components.
Los componentes marcados con el simbolo son
imprescindibles para la protección del equipo, por lo
cual que solo sean reemplazados por los mismos
componentes.
Les componsants marqués du symbole sont indis-
pensables à la sécuritée et ne peuvent être remplacés
qu'avec des composants identiques.
Bauteile, die mit einem gekenzeichnet sind, sind
sehr wichtig und dürfen nur mit den orginal Ersatzteilen
ausgetauscht werden.
I componenti contrassegnati da sono critici per la
sicurezza e devono essere rimpiazzati solo con ricambi
di valore identico.
– 18 –
Q3
Regulator LM337
SS-1376
Q30
XSTR MMBT5088L NPN
SS-0114
Q31
XSTR MMBT5088L NPN
SS-0114
Q32
XSTR MMBT3906LT1 PNP
SS-0791
Q33
XSTR MMBT3906LT1 PNP
SS-0791
Q35
XSTR MMBT3906LT1 PNP
SS-0791
Q37
XSTR MPS6521
SS-209
Q38
XSTR MMBT3906LT1 PNP
SS-0791
Q39
XSTR MMBT3906LT1 PNP
SS-0791
Q5
XSTR MMBTA06L
SS-102SM
Q6
XSTR MMBT3906LT1 PNP
SS-0791
Q7
XSTR MMBT3906LT1 PNP
SS-0791
Q8
XSTR MMBT3904LT1 NPN
SS-0792
U1
OPAMP TL072CD
SS-143SM
U112
OPAMP TL072CD
SS-143SM
U2
OPAMP TL072CD
SS-143SM
U3
OPAMP TL072CD
SS-143SM
U4
OPAMP TL072CD
SS-143SM
U5
COMPTR QUAD LM339
SS-730SM
U7
OPAMP TL072CD
SS-143SM
U8
OPAMP TL072CD
SS-143SM
DS1
SW SIDE ACT DIP 4 POS
SW-1649
DS12
SW SIDE ACT DIP 4 POS
SW-1649
DS4
SW SIDE ACT DIP 4 POS
SW-1649
DS8
SW SIDE ACT DIP 4 POS
SW-1649
J1
CONN XLR NEUTRIK NC3FAH-2-0 CC-2339
J2
RCA JACK, SINGLE WHITE, GOLD CCH-232
JW1
SH 2X3 JUMPER
CC-648
JW1
HDR 6 PIN DUAL ROW
CC-673
V120
RES 0 OHM 1/4W (JUMPER WIRE) RMP/4-0000-03
VV120
RES 0 OHM 1/4W (JUMPER WIRE) RMP/4-0000-03
6.5" Woofer
FG26387WP
1" Tweeter
SPK10424
TRM6 MEHSA Bar
WP-2439
AC6
CONN IEC POWER INLET
CC-1174
CHASS1
HARNESS P1000 CHASSIS GND
FA-1401-A
FUSE 3A 3AG SLO BLO
FS-003SB
FUSE HOLDER CAP 3AG
FS-1175
FUSE HOLDER BODY PC MOUNT FS-1176
TS1
THERMISTOR 10K EPOXY
SS-0426-066
Power Switch
SHW9840
IEC Linecord
WIR9856
Transformer
TT-2326-E
MODEL: TRM6.1CE (230 VAC 50/60 Hz)
RES 0 OHM 1/4W (JUMPER WIRE)
RMP/4-0000-03
FUSEHOLDER CAP 5X20mm
FS-1269-A
5X20mm 0.8A SLO-BLO FUSE
FS-1484-A
European Linecord
WIR10138
