Dimensional Data
Dimensional Data For All Models
Air
Defrost
Model
Electric and
Hot Gas
Defrost Model
No.
of
Fans
Dimensions
A
B
C
D
6 FPI
6 FPI
FPI
in.
mm
in.
mm
in.
mm
in.
mm
040
035
-
1
9.50
749.3
17.5
438.1
-
-
-
-
052
040
-
1
9.50
749.3
17.5
438.1
-
-
-
-
065
047
041
1
9.50
749.3
17.5
438.1
-
-
-
-
070
-
-
2
5.50 1,155.7 33.5
845
-
-
-
-
090
065
-
2
5.50 1,155.7 33.5
845
-
-
-
-
104
-
-
2
5.50 1,155.7 33.5
845
-
-
-
-
120
075
068
2
5.50 1,155.7 33.5
845
-
-
-
-
130
090
080
2
5.50 1,155.7 33.5
845
-
-
-
-
140
120
102
3
61.50 1,562.1 9.5
1,251
-
-
-
-
156
-
-
3
61.50 1,562.1 9.5
1,251
-
-
-
-
180
140
-
3
61.50 1,562.1 9.5
1,251
-
-
-
-
208
160
-
4
77.50 1,968.5 65.5
1,657
-
-
-
-
-
180
136
4
77.50 1,968.5 65.5
1,657
-
-
-
-
260
200
170
5
93.50 2,374.9 81.5
2,064
8.63 1,235.1 3.63
828.7
312
240
204
6
109.50 2,781.3 97.5
2,470
8.63 1,235.1 8.63 1,235.1
370
280
235
6
109.50 2,781.3 97.5
2,470
8.63 1,235.1 8.63 1,235.1
NOTE: Hanger brackets will accept 3/8” / 9.5 mm hanger rods.
