The standard design for the bohn Low Profile Evaporator incorporates a hot gas loop in the drain pan. Utilizing a hot gas
loop is ideal for hot gas defrost applications where high temperature gas can be maintained to defrost both the evaporator
drain pan and coil.
For applications where cooler (lower) temperature hot gas is used for defrosting, bohn offers optional electric heater
elements in the drain pan to ensure quick and efficient defrost of the drain pan allowing condensate to drain quickly, saving
the hot gas for efficient evaporator coil defrost.
If the optional electric heating element drain pan is preferred, please specify when ordering, there is no additional charge.
Physical Data
Model HGT
Hot Gas Defrost
Model
No. of
Fans
Connections (in.)
Approx.
Net Wt.
Coil
Inlet
ODF
Suction
ID
External
Equalizer
OD
Drain
MPT
Side
Port
OD
Hot Gas
Pan Conns.
OD
lbs. kg
6 F
ins P
er I
nch
HGT035
1
5/8
5/8
1/4
3/4
3/8
5/8
6
12
HGT040
1
5/8
5/8
1/4
3/4
3/8
5/8
8
13
HGT047
1
5/8
5/8
1/4
3/4
3/8
5/8
31
15
HGT065
2
5/8
5/8
1/4
3/4
3/8
5/8
5
21
HGT075
2
5/8
7/8
1/4
3/4
3/8
5/8
7
22
HGT090
2
7/8
7/8
1/4
3/4
3/8
5/8
50
23
HGT120
3
7/8
7/8
1/4
3/4
3/8
5/8
6
29
HGT140
3
7/8
7/8
1/4
3/4
3/8
5/8
6
30
HGT160
4
7/8
1-1/8
1/4
3/4
3/8
5/8
83
38
HGT180
4
1-1/8
1-1/8
1/4
3/4
3/8
5/8
86
40
HGT200
5
1-1/8
1-1/8
1/4
3/4
3/8
5/8
103
47
HGT240
6
1-1/8
1-1/8
1/4
3/4
3/8
5/8
13
56
HGT280
6
1-1/8
1-1/8
1/4
3/4
3/8
5/8
16
57
F
ins P
er I
nch
HGT041
1
5/8
5/8
1/4
3/4
3/8
5/8
30
14
HGT068
2
5/8
7/8
1/4
3/4
3/8
5/8
6
21
HGT080
2
5/8
7/8
1/4
3/4
3/8
5/8
9
23
HGT102
3
7/8
7/8
1/4
3/4
3/8
5/8
61
28
HGT136
4
7/8
1-1/8
1/4
3/4
3/8
5/8
8
38
HGT170
5
7/8
1-1/8
1/4
3/4
3/8
5/8
10
47
HGT204
6
7/8
1-1/8
1/4
3/4
3/8
5/8
1
56
HGT235
6
1-1/8
1-1/8
1/4
3/4
3/8
5/8
15
57
