36
Ventilation Slot
if cabinet doesn't fit to ceiling
51 x 457mm minimum area
Ventilation Slot
if cabinet fits
to ceiling
51 x 457mm
minimum area
50mm
air
gap
50mm
air
gap
Tall Cabinet
as above
Cabinet
Side
Trim
Built
Under
560mm min
574mm max
550mm min
excluding pipes
and other projections
578mm min
585mm max
When fitting a hob above an oven always
use these installation instructions
in conjunction with the hob instructions.
Use 2.5mm
2 High Temp Cable. Refer to
Electrical Installation.
Oven Door
Viewed down through
cabinet
560mm
Oven
Fig. 1
Fig. 3
Fig. 2
No. 6 x 15mm
(4 Supplied)
1.5mm
INSTALLATION INSTRUCTIONS
