SPARK ARRESTER SERVICE (optional equipment)
Your lawn mower engine is not factory-equipped with a spark
arrester. In some areas, it is illegal to operate an engine without a
spark arrester. Check local laws and regulations. An optional
USDA approved spark arrester is available from an authorized
Honda servicing dealer.
The spark arrester must be serviced every 100 hours to keep it
functioning as designed.
1. Allow the engine to cool, then remove the bolts from the muffler
shield. Remove the muffler shield.
2. Loosen the two set screws and remove the spark arrester.
3. Check for carbon deposits on the spark arrester and the exhaust
port. Brush carbon deposits away. Be careful to avoid damaging
the spark arrester screen.
4. Installation is the reverse of removal. Tighten all hardware securely.
ADDITIONAL INFORMATION
57
MUFFLER
MUFFLER
SHIELD
SPARK ARRESTER
SET
SCREW (2)
BOLT (3)
