SYSTEM CONFIGURATION SYSTEM CONFIGURATION
26 SYSTEM CONFIGURATION 26 SYSTEM CONFIGURATION
Due to the differences between the way surround
modes operate, some modes allow for a greater range
of delay times than others. To avoid problems, we rec-
ommend that delay times be adjusted using the Dolby
Digital mode. If a different mode is selected at a later
time, the AVR 630 will automatically select the closest
delay settings available for the surround mode in use.
Delay times are adjustable only for the Dolby and DTS
modes, so you will notice that the DELAY menu may
not be accessed for other modes, such as Logic 7. In
addition, when a non-Dolby Digital mode such as Dolby
3 Stereo or Pro Logic II is selected, adjustments may be
made to the Surround speakers only.
To set the delay time for a specific input, the
DELAY ADJUST menu (Figure 8) should be
visible on your on-screen display. If the system is not
already at that point, press the OSD Button
U
to bring up the MASTER MENU, press the
¤ Navigation Button o three times or until the
on-screen ➔ cursor is pointing at the DELAY
ADJUST line. Press the Set Button
q to call
up the menu.
Figure 8
Once the DELAY ADJUST menu is on your
screen, note that the default for distance settings is in
feet. If your measurements are in feet, proceed to the
next step; if your measurements are made in meters,
press the
¤ Navigation Button o until the on-
screen ➔ cursor is at the UNIT line on the menu.
Then, press the
‹ / › Navigation Button o so
that METER is highlighted. When the change
in measurement units is made, press the
⁄ / ¤
Navigation Button o to return the ➔ cursor to
the FL position.
With the on-screen ➔ cursor pointing to FL, press
the
‹ / › Navigation Button o until the distance
from the center speaker to the preferred listening
position is entered. Next, press the
¤ Navigation
Button o to move the cursor to the NEXT line
and use the ‹ / › Navigation Button o again to
enter the distance from the main listening position to
the center speaker. Repeat the procedure for all active
speaker positions, first using the
¤ Navigation
Button o to change to the next position, and then
use the ‹ / › Navigation Button o to change
the setting. Note that only the speaker positions that
have been set to
LARGE or SMALL in the
SPEAKER SETUP menu, as shown on
page 23, may be adjusted. The appearance of
three dashes next to a speaker position in place
of a distance setting indicates that you have not
configured an active speaker for that location.
When the delay time for all speaker positions has
been set you may return to the master menu by
pressing the
⁄ / ¤ Navigation Button o until the
➔ cursor is pointing to BACK TO MASTER
MENU and then pressing the Set Button
q.
However, if you have a digital video source or a digital
video display that causes lack of lip sync you may use
the A/V Sync adjust feature to delay the audio signal
as it is sent to all channels (as opposed to the individ-
ual settings) so that the picture and sound are brought
back together. We recommend that this adjustment be
made using the direct access controls on the remote,
as shown below. That enables you to see the image
while making the adjustment; however, you may also
adjust it here using the menu system.
To adjust the A/V Sync delay, press the ⁄ / ¤
Navigation Button o so that the ➔ cursor is
pointing to the A/V Sync Delay line on the menu and
then press the
‹ / › Navigation Button o to delay
the sound sufficiently so that it matches the on-screen
video.
The delay settings may be adjusted at any time using
the remote control and while viewing an on-screen
image by pressing the Delay Select Button
a.
The A/V Sync Delay setting is first, and it may be
adjusted by pressing the Set Button
q within five
seconds of when the A/V SYNC DELAY
message appears in the on-screen display and the
Lower Display Line
$. Then, press the ‹ / ›
Navigation Button o to enter the desired delay
setting that brings the video and sound back in sync.
Press the Set Button
q again to enter the setting.
Note that the A/V Sync delay setting is unique to each
video input source, so you may enter a different set-
ting to compensate for the differences between any
product attached to the Video 1, 2, 3 or 4 inputs.
To change one of the individual speaker positions
directly, press the Speaker Select Button
b,
followed by the ⁄ / ¤ Navigation Button o to
select the desired position as that name appears in the
on-screen display and the Lower Display Line
$.
When the name of the speaker position to be adjusted
appears press the Set Button within five seconds.
Press the
‹ / › Navigation Button o to enter
the desired delay setting for that speaker and then
press the Set Button
q to enter the setting. The
⁄ / ¤ Navigation Button o may be used to
select another position, or you may simply wait five
seconds for the system to time out and return to
normal operation.
When all delay settings made using the menu system
have been completed, press the
⁄ / ¤ Navigation
Button o until the ➔ cursor is pointing to the
BACK TO MASTER MENU line and press
the Set Button
q.
Output Level Adjustment
Output level adjustment is a key part of the configura-
tion of any surround sound product. It is particularly
important for a digital receiver such as the AVR 630,
as correct outputs ensure that you hear soundtracks
with the proper directionality and intensity.
IMPORTANT NOTE: Listeners are often confused
about the operation of the surround channels. While
some assume that sound should always be coming
from each speaker, most of the time there will be little
or no sound in the surround channels. This is because
they are only used when a movie director or sound
mixer specifically places sound there to create ambi-
ence, a special effect or to continue action from the
front of the room to the rear. When the output levels
are properly set, it is normal for surround speakers to
operate only occasionally. Artificially increasing the
volume to the rear speakers may destroy the illusion
of an enveloping sound field that duplicates the way
you hear sound in a movie theater or concert hall.
Before beginning the output level adjustment process,
make certain that all speaker connections have been
properly made. The system volume should be set to
the level that you will use during a typical listening
session. While the AVR 630 allows you to set output
levels manually, we recommend that the EzSet system
be used when the AVR is first installed to establish the
initial level settings.
Using EzSet
Harman Kardon’s exclusive EzSet remote makes it possi-
ble to quickly and accurately set the AVR 630’s output
levels without the use of a sound-pressure meter,
although manual adjustment is also available. However,
for the easiest setup, follow these steps while seated in
the listening position that will be used most often:
* D E L A Y A D J U S T *
F L : 1 2 f t S B R : 1 0 f t
C E N : 1 2 f t S B L : 1 0 f t
F R : 1 2 f t S L : 1 0 f t
S R : 1 0 F t S U B : 1 0 f t
U N I T : F E E T M E T E R
A / V S Y N C D E L A Y : 0 m S
B A C K T O M A S T E R M E N U
→
