Hellenbrand TS Series - Manual (Page 4)

RATED CAPACITY
RESIN PIPE SIZE LOW SALT MEDIUM SALT HIGH SALT FLOW RATE PEAK BWK
MODEL CU.FT. (INCHES) GRAINS/LBS GRAINS/LBS GRAINS/LBS CONT. 15 PSI 25 PSI GPM
TS-30-1 1.0 1" 19,000/6 28,000/10 32,000/15 15.0 20.0 2.0
TS-45-1 1.5 1" 28,500/9 42,000/15 48,000/22.5 16.0 22.0 2.4
TS-60-1 2.0 1" 38,000/12 56,000/20 64,000/30 20.0 26.0 3.5
TS-60-1.5 2.0 1.5" 38,000/12 56,000/20 64,000/30 31.4 43.0 3.5
TS-90-1 3.0 1" 57,000/18 84,000/30 96,000/45 19.0 26.0 4.0
TS-90-1.5 3.0 1.5" 57,000/18 84,000/30 96,000/45 30.2 41.7 4.0
TS-120-1 4.0 1" 76,000/24 112,000/40 128,000/60 20.0 27.0 5.0
TS-120-1.5 4.0 1.5" 76,000/24 112,000/40 128,000/60 33.2 45.2 5.0
TS-150-18-1 5.0 1" 95,000/30 140,000/50 160,000/75 21.0 28.0 7.0
TS-150-18-1.5 5.0 1.5" 95,000/30 140,000/50 160,000/75 36.0 49.0 7.0
TS-150-22-1 5.0 1" 95,000/30 140,000/50 160,000/75 22.0 29.0 9.0
TS-150-22-1.5 5.0 1.5" 95,000/30 140,000/50 160,000/75 41.5 55.3 9.0
TS-180-18-1 6.0 1" 114,000/36 168,000/60 192,000/90 20.0 27.0 7.0
TS-180-18-1.5 6.0 1.5" 114,000/36 168,000/60 192,000/90 34.0 47.0 7.0
TS-180-22-1 6.0 1" 114,000/36 168,000/60 192,000/90 21.0 28.0 9.0
TS-180-22-1.5 6.0 1.5" 114,000/36 168,000/60 192,000/90 40.0 53.6 9.0
TS-210-1 7.0 1" 133,000/42 196,000/70 224,000/105 20.0 27.0 9.0
TS-210-1.5 7.0 1.5" 133,000/42 196,000/70 224,000/105 38.5 51.9 9.0
TS-240-1.5 8.0 1.5" 152,000/48 224,000/80 256,000/120 42.0 56.0 12.0
TS-270-1.5 9.0 1.5" 171,000/54 252,000/90 288,000/135 41.0 54.8 12.0
TS-300-1.5 10.0 1.5" 200,000/60 280,000/100 320,000/150 40.5 54.0 12.0
OPERATING CONDITIONS
1. Water Pressure 30 - 100 psi.
2. Water temperature is not to exceed 110 F and cannot be subject to freezing
conditions.
3. Limit of 2 ppm of Ferrous Iron. Add 3 grains of hardness per ppm of iron when
sizing.
4. Electrical requirements: 115Vac - 15 Amp Circuit.
5. Product improvement designs are subject to change without notice.
6. Refer to Hellenbrand Bulletin 2050 “Flow Rates and Soft Water Quality (Hardness
Leakage) if your application requires that levels of hardness leakage do not exceed “x”.
TS Physical Specifications
TS Capacity
TS-1.5" INLET OUTLET
SERIES HEIGHT WIDTH TWIN HEIGHT HEIGHT
MODEL (INCHES) (INCHES) (INCHES) (INCHES) (INCHES)
TS-60 63 37 56 56.5 57.5
TS-90 73 38 58 67.5 68.5
TS-120 73 46 68 67.5 68.5
TS-150-180-18 76 46 68 69.0 70.5
TS-150-210-22 75.5 52 80 65.5 70.5
TS-240 83 54 84 65.5 78.0
TS-270-300 83 54 84 73.5 78.0
TS-1.5” Series Dimensions
