TO RELEASE CHAIR
Slide knob this direction
Slowly back chair
off platform
NOTE: During transport, vibration
may cause the chair to tighten itself in
the locking device, making the release
knob difficult to slide. To overcome this,
simply drive the chair forward a bit.
This will take pressure off the knob,
allowing an easier release.
UNLOADING THE POWER CHAIR
ON
DOWN
UP
1
Insert and turn key.
Press down on switch
to lower platform.
To avoid bending over,
you may wish to release
chair from Locking Device
prior to lowering platform.
Be sure the drive wheels
are engaged, and the chair's
power is OFF.
Once the chair has left the locking device,
it automatically resets itself to accept the
next time the chair needs to be transported.
No adjustment of the release knob is required. Raise the platform
by pressing up on
the switch until
motor's clicking
noise is heard.
Platform will fold
automatically.
Remove the key
if desired.
2
3
AL550
OPERATION
19
