LIFT PREPARATION
AL 560
3/16 “
ALLEN WRENCH REQUIRED
FOR ADJUSTMENT PURPOSES,
ALL PLATFORM COMPONENTS ARE
SHIPPED LOOSE
AND MUST BE FIRMLY TIGHTENED
IF NECESSAR
Y, T
HE
COMPONENTS MAY
BE
RE-ARRAN
GED FOR
FRONT or REAR
DRIVE WHEELS
X4
X4
X8
X8
US
E FOR DRIVE WHEELS
US
E F
OR
D
RIV
E W
HE
EL
S
USE FOR DRIVE WHEELS
US
E F
OR
D
RIV
E W
HE
EL
S
SLIDE TO CAPTURE CHAIR’S WHEELBASE
ADJUST
BARS and
PLATFORM
SKINS TO
CAPTURE
CHAIRS
WHEELS.
ONCE ADJUSTED
BE SURE TO TIGHTEN ALL FASTENERS
