56 - English
6. MENU FUNCTIONS
To find out the distance from the charging station
to a remote area:
• State a distance that easily exceeds the true
distance. The maximum distance that can be
stated is 500 metres. Set Proportion to 100 % for
the areas where the distance is to be measured
and 0 % for the other areas. Place Automower in
the charging station and select Test OUT
(3-2-5). The mower will now leave the charging
station directly according to the stated direction.
The distance will be shown on the display,
stated in metres, as the mower runs. Stop the
mower after the required distance and read the
distance. Enter the number of metres shown in
Distance for the area in question. Reset the
Proportion values when testing is finished.
Garden shape (3-3)
Automower can be set according to three garden
shapes: Open, Normal and Complex.
This setting affects how Automower covers a working
area when it mows. Above all it influences the turning
angles and how often the mower changes direction.
The Open setting optimises the pattern of movement
for an open garden. If the garden contains a lot of
small areas linked with passages a better function will
be obtained with the Complex setting. Select:
• Open (3-3-1)
for an open lawn area with few obstacles and no
passages.
when steep slopes give an uneven mowing result.
• Normal (3-3-2)
for an average number of obstacles and/or
passages.
• Complex (3-3-3)
for a large lawn area and large number of
obstacles and/or passages.
3-3
3-3-
Open
Normal
Complex
Exit angles
Follow loop
Garden shape
Advanced
