KK-K9-D22-K_INST_9-07


INSTALLATION INSTRUCTIONS KK-K9-D22-K

K-9 TRANSPORTATION KIT

2005-2008 DODGE MAGNUM


TOOLS REQUIRED:

Power Drill
Drill Bit Set
Standard Wrench Set
Standard & Metric Socket Set
Ratcheting Wrench

Screwdriver Set (Cordless powered)
Wire cutters
Wire Strippers
Crimping tool
Caulking gun


HARDWARE:
QTY: DESCRIPTION: USED

FOR: PART

#:

8

#10 x ¾” Stainless flat head screw

Door Panel (top lip)

GSM34151

32

#10 x ¾” Stainless sheet metal screw

Door Panel

GSM34170

40

#10 x ½” Stainless sheet metal screw

Fillers/Step sill

GSM34169

8

#10 x ½” Stainless flat head screw

Window guard hinge

GSM34150

29

¼-20 x ½” Stainless carriage bolt

Basic unit assembly

GSM32022

44

¼-20 Serrated nut

Basic unit assembly

GSM30023

7

¼-20 x ¾” Stainless carriage bolt

Lexan filler

GSM32024

8

¼-20 x ¾” Hex head bolt

Front cage bracket

GSM33001

4

¼” x ¾” Hex head lag bolt

Front cage bracket

GSM33060-1

1 Tube

silver

silicone

Sealant

PRM97343

3

#10 x ¾ Sheet metal screw

Dome light

GSM33195


COMPONENTS:

QTY: DESCRIPTION:
1 Front

Cage

1 Rear

Cage

1 Floor
1 Ceiling
2

Front Cage Upper Lexan Fillers

2

Front Cage Lower Aluminum Fillers

2

Step Sill Aluminum Fillers

2

Rear Cage Lower Aluminum Fillers

2

Rear Cage Upper Aluminum Fillers

2 Aluminum

Ceiling

Fillers

2

(2-pc) Front Cage Brackets

2

Aluminum Door Panels

2

Hinging Window Guards w/brackets

1

Dome Light Kit

1 Rubber

Mat

1 Rear-Mounting

Foot
