Connecting your devices – Hitachi PJ-LC9 User Manual
Page 15
13
ENGLISH
Preparations
Examples of connection with a VCR/DVD player
Connecting your devices
• Secure the screws on the connectors and tighten.
• For an audio cable with 2 RCA connectors to 2 RCA connectors, use the
accessory audio adapter.
• For a component video cable with 3 RCA connectors to 3 RCA connectors,
use the accessory component video adapter.
NOTE
K
K
K
S-Video out
Video out
Audio out
Audio cable
Audio cable
Audio out
Component video cable
Audio out
Audio cable
Video cable
S-Video cable
Component video out
