PARTS LIST
Item Qty. Part No. Description
1 3 990062 Pole Section 46-1/4 Long
2 1 900751 Extension Arm
3 1 Backboard
4 1 Rim, (Black or Red)
5 4 203104 Bolt, Hex-Flange 5/16-18x2
6 8* 203309 Washer, 1 O.D.
7 10 203100 Nut, Hex-Flange 5/16-18
8 2 990438 Board Strut, 27 Long
9 2 203223 Bolt, Carriage 5/16-18x1
Item Qty. Part No. Description
10 8 203218 Washer, 5/16 Flat
11 4 200516 Cover-Bolt End
12 2 203217 Bolt, Carriage 5/16-18x1-1/2
13 2 203291 Spacer-Flexible Rubber
14 2 201611 Bolt, Hex-Flange 5/16-18x3
15 1 207103 Pole Cap-Plastic
16 12* 200120 Clips, Net Holders, (Red)
12* 200121 Clips, Net Holders, (Black)
17 1 Net
#5 (4)
#12 (2)
#14 (2)
#9 (2)
#11 (4)
#10 (8)
#6 (8*)
#13 (2)
#7 (10)
HARDWARE IDENTIFIER
