Thank you for purchasing a Harman Kardon AVR 125. This Quick-Start
Guide will help you with a basic system installation. For detailed information
on any step in this Guide, please refer to the pages referenced in the
Owner’s Manual. We strongly recommend that you read the Owner’s
Manual for complete details on how to install, configure and operate the
AVR 125, as well as for the important safety information it contains.
Figure 1 – Speaker Placement
The colors shown for each speaker correspond to
the matching output terminal connection on the back
of the AVR 125 (see page 14).
FRONT
LEFT
SPEAKER
(White)
CENTER
SPEAKER
(Green)
SUBWOOFER
(Purple)
SURROUND
LEFT
SPEAKER
(Blue)
FRONT
RIGHT
SPEAKER
(Red)
SURROUND
RIGHT
SPEAKER
(Gray)
Step 1. Place your speakers in the listening room
(see page 16).
SPEAKER PLACEMENT
Connections Color Guide
Audio Connections Left Right
Front
Center
Surround
Subwoofer
Digital Audio Connections
Coax
Optical
Video Connections
Composite
S-Video
Match the colored jacks on the AVR 125 to the appropriate
jacks on your source equipment or speakers. The colors are
standardized, but not all equipment or connectors use them.
AVR 125 QUICK-START GUIDE
