Heat & Glo • 8000CF-OAK-IPI • 2059-900 Rev. R • 6/09 25
Figure 7.5
Top Vent - Horizontal Termination - (continued)
Three Elbows
H
2
H
1
V
2
V
1
V
1
Min. H
1
Max. V
2
Min. H
2
Max. V
1
+ V
2
Min. H
1
+ H
2
Max.
1 ft. 305 mm 3 ft. 914 mm 1 ft. 305 mm 3 ft. 914 mm 2 ft. 610 mm 6 ft. 1.8 m
2 ft. 610 mm 6 ft. 1.8 m 2 ft. 610 mm 6 ft. 1.8 m 4 ft. 1.2 m 12 ft. 3.7 m
3 ft. 914 mm 9 ft. 2.7 m 3 ft. 914 mm 9 ft. 2.7 m 6 ft. 1.8 m 18 ft. 5.5 m
H
1
+ H
2
= 20 ft. (6.1 m) Max. V
1
+ V
2
+ H
1
+ H
2
= 50 ft. (15.2 m) Max. V
1
= 1 ft. (305 mm) Min.
