Service Parts Service Parts Diagram 36 in. See-through W
oodburning Fireplace
Part number list on following page.
HST
-42D
1
2
10
9
8
11
7 6 5
Side of Fireplace
13
15
3
12
14
Duct sold separately
4
Beginning Manufacturing Date:
Aug 2001
Ending Manufacturing Date:
Active
5/08
Service Parts Service Parts List 36 in. See-through W
o
odburning Fireplace
HST
-42D
IMPOR
TANT
: THIS IS DA
TED INFORMA
TION. When requesting service or replacement
parts for your appliance please provide model number and serial number
. All parts listed
in this manual may be ordered from an authorized dealer
.
Stocked at Depot
ITEM
D
ESCRIPTION
COMMENTS
P
A
RT NUMBER
1
Damper Blade
Assembly
22890
N
Damper W
eight
13944B
N
Damper Rod
28900
N
2
S
tarter Section
Assembly
22069B
X
3
Top Standof
fs
Qty
. 4 req.
11
864i
N
4
S
moke Shield
Qty
. 2 req.
20399
N
5
B
ack Refractory
Qty
. 2 req.
27068
N
6
S
ide Refractory
Qty
. 4 req.
27067
N
7
F
irescreen Assembly
Qty
. 4 req.
26038
X
Firescreen Handle
1 ea.
4021-149
N
8
Door Support
Qty
. 2 req.
4012-035
N
9
Ashlip
Qty
. 2 req.
20401
N
10
Hearth Refractory
13321B
N
11
Damper Control
20549
N
12
Grate
GR12
Y
13
Air Kit
AK17
N
14
Outside Air
Plate Assembly
19081A
N
15
Outside Air
Shield
33271
Y
AK17 Installation Instructions
31
168
N
Air Kit Fastener Pack
17916B
N
Bottom Door
T
rack
(used for upper)
Qty
. 2 req.
4012-002
N
Door T
rack
(used for lower)
Qty
. 2 req.
15425
N
Firescreen Rod
Qty
. 4 req.
11
866B
Y
Gas Access
Panel
(for use with
Air Kit)
Qty
. 2 req.
31636
N
Grate Clip
Qty
. 2 req.
28062
N
Grate Retainer
Qty
. 2 req.
17365D
N
Nailing Flange
Qty
. 8 req.
31
190
N
Refractory Bracket
Qty
. 2 req.
13328
N
Refractory Retainer
Qty
. 2 req.
11
847
N
Refractory Standof
f
Qty
. 2 req.
13327D
N
Smoke De
fl ector
Qty
. 2 req.
20603B
N
Strip Protector
Qty
. 4 req.
18320
N
Installation Instructions & Owner's Manual
27177
N
Beginning Manufacturing Date:
Aug 2001
Ending Manufacturing Date:
Active
