A S S E M B LY
I N S T R U C T I O N S
HF4985 A
SSEMBLY
F R A M E A S S E M B L Y
Step 2e
1 - Right Support Beam
2 - Left Support Beam
5 - Rear Support
7 - Guide Rod Support
12 - 25mm Linear Shaft
Part Descriptions
A - -13UNC x 4” Hex Bolt
AA - 1/2” Flat Washer
BA - 1/2” Nylok Nut
1/2”
Hardware Descriptions
Page - 13
Slide the top of (12) up into the hole on the bottom of (5). Next, slide
the bottom of (12) into (7) and secure one (7) to (1), and the other (7) to
(2). Wrench Tighten bolts.
