Step 2c – Hoist Fitness HF4985 User Manual
Page 10
A S S E M B LY
I N S T R U C T I O N S
HF4985 A
SSEMBLY
F R A M E A S S E M B L Y
Step 2c
1 - Right Support Beam
2 - Left Support Beam
3 - Top Cross Member
5 - Rear Support
11 - Bar Rack
Part Descriptions
A -
-13UNC x 4” Hex Bolt
C - 1/2”-13UNC x 4 1/4” Hex Bolt
AA - 1/2” Flat Washer
BA - 1/2” Nylok Nut
1/2”
Hardware Descriptions
Page - 9
