A S S E M B LY
I N S T R U C T I O N S
HF4985 A
SSEMBLY
F R A M E A S S E M B L Y
Step 2d
4 - Base Support
8 - Olympic Weight Mount
9 - Olympic Weight Bar
11 - Bar Rack
12 - Linear Shaft
13 - Hook Sleeve
14 -
Roller Hook
Part Descriptions
D - 3/8-16UNC x 2 1/4” Hex Bolt
AB - 3/8” Flat Washer
BB - 3/8” Nylok Nut
Hardware Descriptions
Page - 11
In this step; first, slide (13) into (14) and secure to one side of (9),
repeat for other side of (9) and ook (9) onto both
(11)’s. Next, place a finger of light grease (lithium, super lube, ect) into
the inside of the bearings on both (8)’s. Using your finger, press the grease
into the ball-bearings and their tracks. Repeat until the ball-bearing
tracks are full of grease. Slide (12) into (8), then (8) into (9) and let (12)
rest on (4), it will be secured in a late step. Repeat process for other side
of (9).
Wrench Tighten bolts.
H
