NOTE: PIPES OVERLAP 32 mm AT EACH JOINT.
FIGURE 6. DVP-Series Balanced Flue Component Specifications
(127 mm inner pipe / 203 mm outer pipe)
DVP90ST
31.9cm
28.6cm
18.4cm
3.2cm TYP
1.3cm TYP
21.7cm
DVP36
DVP48
121.9cm
61.0cm
91.4cm
10.2cm
15.2cm
DVP4
DVP6
30.5cm
DVP12
5.1cm
MIN.
DVP12A
31.0cm
MAX.
DVP24
25.1cm
45.0
O
26.0cm
DVP45
36.2cm
.
