Dismantling of the machine hoods
Engine hood
The engine is accessible for servicing when the
engine hood is lifted up.
Tilt the seat forward, release the rubber strap under
the seat, and tilt the hood backwards.
Front hood Rider 11 and Rider 13 H
Release the screws in the front hood (3) and lift off
the hood.
MAINTENANCE
Front hood Rider 11 Bio and Rider 13 H Bio
Release the catch and lift off the hood.
