B. Fireplace Components (continued)
GR23 & GR24Inte-
gral Grate
Bi-fold Glass Doors
DM1736
DM1742
Traditional Brick Pattern Refractory
Herringbone Pattern Refractory
16 in.
(406 mm)
52 in.
(1321 mm)
1/2 in.
(13 mm)
HX3 Hearth Extension
20 in.
(508 mm)
66 in.
(1676 mm)
1/2 in.
(13 mm)
HX4 Hearth Extension
AK22 Outside Air Kit
FK23 Fan Kit
BC-10
Fan Speed Motor Control
JK9
Junction Box
