G. installation of fan – Heat & Glo Fireplace EM-485T User Manual
Page 24
24
G. Installation of Fan
Follow installation instructions supplied with fan kit.
Figure 7.9 Attach the Heat Shield
Figure 7.10 Attach the Junction Box
Bend this tab down
90 degrees
Bend this half tab
down 90 degrees
Slide the flanges of the junction box
through the slots in the bracket.
Figure 7.7 Position Bracket on Junction Box
Bend remaining half
tab down 90 desgrees.
Figure 7.8 Secure Bracket to Junction Box
Figure 7.6 Prepare Junction Box Bracket
Heat & Glo • EM-415, EM-485 • 33056 • Rev W • 10/08
