8
Parameter Description
More Setting button Press this button for more settings including disable/enable WEP
and Power Saving Mode. Please refer to Section 3.2, 3.3 and 3.4.
Link Status Displays the status of the wireless connection.
Signal Strength This bar shows the signal strength level. The higher percentage
shown in the bar, the stronger the radio signal received by the
adapter will be . This indicator helps you find the optimal position
and location of your network for the best connection.
Link Quality This bar indicates the quality of the link. The higher the
percentage, the better the quality. (Less Noise, Interference)
TX Frame Shows the number of data frames that are transmitted by the
adapter successfully.
RX Frame Shows the number of data frames that are received by the
adapter successfully.
3.2 General Connection Setting
In the “More Setting...” screen, us ers are able to designate which wireless networks that
th e adapter intends to connect to. In this section you may also enable/disable WEP data
encryption (Security, Highly Recom m ended), and save or load current setting values
into/from a file, etc. for future use.
