HONDA TL5040 User Manual
Page 19
DESCRIPTION
REF.
PTO SHIELD
1
SHAFETY PIN DIAM. 3
2
LIFT PIN CAT 0
3
SCREW M12x80
4
MAST SUPPORT
5
MAST BRACE
6
MAST SPACER
7
SPRING WASHER DIAM. 12
8
NUT M12 L.
9
NUT M12x1,25 H
10
SCREW M12x1,25x35
11
RH GEARBOX HALF CLAMP
12
REAR SHIELD CHAIN HOOK
13
LH GEARBOX HALF CLAMP 14
OIL PLUG 3/8" G
15
GEARBOX HOUSING
16
SPACER
17
ClRCLlP E 35
18
SHIM
19
BALL BEARING 6207
20
GASKET
21
GEARBOX FRONT COVER
22
SCREW M12x25
23
OIL SEAL 35x72x10
24
BEVEL GEAR Z=41
25A
PTO SHAFT PINION Z=10
25B
KEY 10x8x30
26
SHAFT PIPING
27
NUT M10 H
28
SPRING WASHER DIAM. 10
29
SHAFT
30
BEARING 6207
-
1Z
31
CHAIN CASE
32
CHAIN CASE GASKET
33
UPPER SPROCKET
34
FLAT WASHER DIAM. 10
35
BEARING LODGING COVER
36
SPACER
37
38
SCREW M12x70
39
CPLT DRIVE CHAIN ASA 50x41
40
LOWER SPROCKET Z=22
41
DESCRIPTION
REF.
SCREW M10x25
42
LH SKID
43
STAND
44
OIL SEAL 40x52x10 RP 45
OIL SEAL LODGING COVER
46
ROTOR
47
REAR SHIELD
48
SPLIT PIN DIAM. 5x35
49
FLAT WASHER DIAM. 12
50
LH SIDE FRAME
51
SCREW M10x20
52
HARDSTEELWASHER
53
TENSIONER ARM SPRING
54
NUT M10 METAL TRIBLOCK
55
CHAIN TENSIONER ARM
56
FLAT WASHER DIAM. 10
57
SCREW M10x35
58
SCREW M10x60
59
FRAME
60
HITCH PIN BRACKET
61
SCREW M12x90
62
SCREW M10x30
63
GEARBOX LATERAL SUPPORT
64
SCREW M12x40
65
BUSHING
66
67
RH SIDE FRAME
68
RH SKID
69
SCREW M12x1,25x45
70
GREASE NIPPLE M10x1
71
ROTOR COVER
72
SPEED BLADE RH
73
SPEEDBLADERH
74
REAR SHIELD SPRING
75
REAR SHIELD CHAIN
76
OIL PLUG 3/8" G
77
OIL SEAL 40x52x7
78
NUT M10 L
79
SCREW M12x1,25x30
80
REAR SHIELD PIN DIAM. 12
81
ClRCLlP
I
72
82
17
