SPECIFICATIONS

Power Rating:

Less than 0.02% total harmonic distortion at

any power level up to 115 watts continuous average power
per channel into 8 ohms at any frequency between 20 Hz
and 20 kHz with both channels driven.

Input Impedance: 47,OOO

ohms.

Input Sensitivity:

1.55 volts rms for 1 15 watts into 8 ohms.

IM Distortion ( S M P T E )

Less than O.OOS’%, from 1 watt to 1 15

Damping Factor: 300

to 1 kHz into 8 ohms

watts into 8 ohms. 60 to 10

into 8 ohms

Typical THD at 115 watts into 8 ohms:

I kHz - 0 0025%

__

IO kHz - 0 . 0 0 7 %

20 kHz - 0.012’/‘

Frequency Response into 8 ohms:

- 3 dB. 2 Hz to 160 kHz at 1 watt
+O, -0.5 dB, 6 Hz to 60 kHz at 1 15 watts

Rise Time:

10 kHz. 60 volts peak to peak square wave, 1 0 %

to 9 0 % 2.5 us.

Slew Rate:

10 kHz. 60 volts peak to peak square wave: 30

s.

Semiconductor Complement: 26

transistors. 8 power

Mosfets, 29 diodes, 4 zener diodes. 1 diode bridge.

Typical Channel Separation: 20

Hz:>

75 dB

1 kHz:>85 dB

20

kHz: >6S

dB

Power Consumption:

1 15 watts into 8 ohms: 840 VA;

Quiescent: 125 VA.

Size: 5-1/8” high. 16” wide, 10-l/2” deep.

Signal

to Noise Ratio, unweighted:

Better than 100 dB at 115

watts into 8 ohms.

Net Weight: 26

Ibs.

Shipping Weight: 30 Ibs.

All Specifications are subject to change without notice.

Printed in USA
