308640 19
Parts
Use Only Genuine Graco Parts and Accessories
Part No. 238402, 238852, 238883, and 241070
Ref.
No.
Part No.
Description
Qty.
Ref.
No.
Part No.
Description
Qty.
1
238750
BODY, gun
1
2
106917
ADAPTER, air;
Included with Gun
238402, 238883, and 241070 only
1
113367
COUPLING, air, quick-disconnect;
Included with Gun 238852 only
1
3
276429
TRIGGER, gun
1
5
217489
VALVE, pattern adjustment;
Includes items 5a and 5b
1
5a
168110
S
O-RING, nitrile rubber
1
5b
105456
S
RETAINER, clip
1
6
106903
SPRING, compression, air valve
1
7
178408
CAP, valve, air
1
8
203953
CAP SCREW, hex hd,
10-24 x
0.375” long
1
9
187562
PIN, pivot
1
10
238754
NEEDLE, fluid;
Included with Gun
238402, 238852, and 241070 only;
Includes replaceable items 10a, 10b
1
238755
NEEDLE, fluid, hi-flow;
Included
with Gun 238883 only; Includes
replaceable items 10a and 10b
1
10a
111516
S
O-RING; CV75
1
10b
111517
S
RING, backup; PTFE
r
1
11
238248
TIP GUARD
1
12
107079
O-RING, PTFE
1
13
239781
AIR CAP;
Included with Gun
238402, 238852, and 238883 only
1
239898
AIR CAP;
Included with Gun
241070 only
1
14
GG4XXX
SPRAY TIP; Customer’s choice;
See Chart on page 22.
Includes
replacement gasket 183616
1
15
238427
DIFFUSER-SEAT;
Included with Gun
238402, 238852, and 241070 only
1
224855
DIFFUSER-SEAT, hi-flow;
Included
with Gun 238883 only
1
16
178414
SEPARATOR, air
1
17
178422
GASKET, fluid, Delrin
r
;
1 sent unassembled
2
18
187521
GASKET, fluid; acetal homopolymer
(black),
1 sent unassembled
2
19
224868
TRIGGER EXTENSION
2
23
187504
NUT, needle
1
24
178765
NUT, packing, air
1
25
105452
U-CUP, PTFE 1
26
217487
VALVE, air
1
29
238228
GUARD, trigger
1
30
191026
CONNECTOR, fluid
1
31
Y
222385
WARNING CARD (not shown)
1
34
187737
TOOL, needle assembly
1
35
Y
172479
TAG, instruction (not shown)
1
Y
Replacement Warning labels, tags and cards are
available at no cost.
Repair Kits
Kit No. and
D
i
i
Includes:
Description
Ref. No.
Part No.
Description
224949
Gun Repair
Kit
5a
5b
6
10
10a
10b
12
15
17
18
25
26
168110
105456
106903
238754
111516
111517
107079
238427
178422
187521
105452
217487
O-Ring
Retainer
Spring
Needle
O-Ring
Backup Ring
O-Ring
Diffuser-seat
Gasket
Gasket
U-Cup
Valve
235304
Fluid Section
Repair Kit
10
10a
10b
15
17
18
238754
111516
111517
238427
178422
187521
Needle
O-Ring
Backup Ring
Diffuser-seat
Gasket
Gasket
238739*
Hi-flow Gun
Repair Kit
5a
5b
6
10
10a
10b
12
15
17
18
25
26
168110
105456
106903
238755
111516
111517
107079
224855
178422
187521
105452
217487
O-Ring
Retainer
Spring
Needle
O-Ring
Backup Ring
O-Ring
Diffuser-seat
Gasket
Gasket
U-Cup
Valve
238738*
Hi-flow Fluid
Section
Repair Kit
10
10a
10b
15
17
18
238755
111516
111517
224855
178422
187521
Needle
O-Ring
Backup Ring
Diffuser-seat
Gasket
Gasket
* Must be used with tips larger than 0.025 in. (0.635 mm).
