Huffy 211387 - Manual (Page 11)

11
5/99 P/N 211387
printed on recycled paper
50"
(127 cm)
Secure screw hook (39) into wall, approximately
50” (127 cm) up from floor as shown.
IMPORTANT! It is necessary to install screw hook
into a wall stud.
Remove tie down stake (37) from ground and
detach rope (36). Rotate system up onto the front
wheels and roll toward the wall. Secure system with
rope (36) on screw hook (39).
39
36
8.
7.
36
39
6.
Carefully rotate system up on its side to remove
water or sand from tank.
Remove knob set (32, 31, and 33) from the rim assembly
and re-insert knob set into top locking position.
5.
32
33
31
