Hitachi ULTRA MAX 695 232133 User Manual

Ultra r max 695 airless paint sprayer, Instructions-parts list, Related manuals

background image

308801

Rev. E

First choice when

quality counts.

t

7727A

7728A

Model 232133

Model 232131

Related Manuals

Displacement Pump

308815

. . . . . . . . . . . . . . . . .

Fluid Filter

308249

. . . . . . . . . . . . . . . . . . . . . . . . . .

Spray Gun

307614

. . . . . . . . . . . . . . . . . . . . . . . . .

Spray Tip

308644

. . . . . . . . . . . . . . . . . . . . . . . . . . .

INSTRUCTIONS-PARTS LIST

INSTRUCTIONS

This manual contains important
warnings and information.
READ AND KEEP FOR REFERENCE.

ELECTRIC, 120 VAC

ULTRA

r MAX 695

Airless Paint Sprayer

3000 psi (210 bar, 21 MPa) Maximum Working Pressure

Models 232133 and 232131, Series A

Complete sprayer with hoses, gun, RAC IV

r DripLesst

Tip Guard and SwitchTip

t

Model 232132 and 232130, Series A

Basic sprayer only

GRACO INC.

P.O. BOX 1441

MINNEAPOLIS, MN

55440–1441

ECOPYRIGHT 1997, GRACO INC.

Graco Inc. is registered to I.S. EN ISO 9001
