MODEL CT20 FACTORY NO. 11054x37NA
26 MS−3615MA
REF .
TRANSMISSION
480
482
483
481
490 492
491
497 490
494
493
497
KEY
NO. PART NO. DESCRIPTION
480 601 00 25 01 Shield, Tine
481 601 00 12 87 Screw, 1/4−20x5.50
482 601 00 00 18 Spacer, Flange
483 601 00 23 18 Nut, 1/4−20
490 601 00 06 02 Washer, Felt
491 531 30 74−52 Tine Assy. Inner LH
492 531 30 74−53 Tine Assy. Outer LH
493 531 30 74−54 Tine Assy. Inner RH
494 531 30 74−55 Tine Assy. Outer RH
497 531 30 74−56 Pin, Latch
