10.7kW

1.0kW

48kg

Height 1240mm Width 500mm

Depth 600mm

29 litres

900cm

2

1.65kW

1.0kW

1.65kW

Installation

The cooker is designed to fit between kitchen
cabinets spaced 500mm apart. The space either side
need only be sufficient to allow withdrawal of the cooker
for servicing. It can be used with cabinets one side or
both as well as in a corner setting. It can also be used
free-standing.

This cooker is a class X appliance, as such adjacent
side walls which project above hob level, must not be
nearer to the cooker than 150mm and should be
protected by heat resistant material. Any overhanging
surface or cooker hood should not be nearer 650mm.

Before moving your cooker, switch off at the cooker
control unit, ensure that it is cool.

Open the grill door sufficiently to allow a comfortable
grip on the underside front edge of the oven roof,
avoiding any grill elements.

Take care in moving the cooker as it is heavy. Take
care to ensure that any floor covering is not
damaged.

4

Siting the Cooker

Moving the Cooker

Note

Product Specification

Supply Voltage

230V AC Only

240V AC Only

Supply Frequency

50Hz

50Hz

Total Wattage

9.9kW

Grill Wattage

2.3kW

2.5kW

2.2kW

Main Oven Wattage

2.4kW

Left Front Hotplate

1.8kW

Left Rear Hotplate

1.1kW

Right Rear Hotplate

1.8kW

Right Front Hotplate

1.1kW

Grilling Area

Top Oven Capacity

49.9 litres

Main Oven Capacity

Weight

External Dimensions
Excluding Handles
