Technical specifications
4700n (Q7492A) 4700dn (Q7493A) 4700dtn (Q7494A) 4700ph+ (Q7695A) CM4730 MFP
(CB480A)
CM4730f MFP
(CB481A)
CM4730fsk MFP (CB482A) CM4730fm MFP (CB483A)
Print and copy speed 10 Up to 31 ppm Up to 31 ppm, letter (color and black-and-white); Up to 30 ppm, legal (black-and-white)
First page out, printing Less than 10 seconds letter, Ready; less than 16.5 seconds letter, PowerSave Less than 10 seconds letter, Ready;
less than 17.5 seconds letter, PowerSave
Less than 12 seconds letter, Ready;
less than 25 seconds letter, PowerSave
Print resolution 600 by 600 dpi, with HP ImageREt 3600
Features
Copying Not available Up to 999 copies; reduce or enlarge from 25 to 400% (from scanner glass), 25 to 200% (from ADF)
Faxing Not available Optional via fax
accessory
Fax speed: up to 33.6 kbps; JBIG compression, fax forwarding, fax polling,
broadcasting to up to 100 locations, speed dial (up to 100 numbers), auto fax
reduction, and auto redialing supported
Scanning Not available Color flatbed scanner or ADF; up to 600 by 600 dpi 30 bit (flatbed), up to 600 by 300 dpi 30 bit (ADF);
scan input modes: copy, e-mail, fax, secondary e-mail, folder, workflow
Digital sending Not available Via optional HP Digital Sending Software: secondary e-mail, send-to-folder, send-to-workflow,
authentication, digital fax (send-to-LAN, Windows 2000, Internet); formats: PDF, JPEG, TIFF, MTIFF
Processor 533 MHz RISC
Memory, standard 160 MB total 288 MB total 544 MB total 448 MB: 384 MB RAM and 64 MB fixed memory
Available memory slots Expandable via one available DIMM slot for memory and two available flash memory card slots for font
cards or third party solutions
Expandable via 256 DIMMS, two available flash memory slots for font cards or third party solutions
Memory, maximum 544 MB RAM 512 MB RAM
Hard disk Optional 20 GB HP high-performance via EIO slot 40 GB HP high-performance
Maximum monthly duty cycle 11 100,000 pages 175,000 pages
Recommended monthly
volume 12
3,000 to 10,000 pages 5,000 to 9,000 pages
Media
Paper handling 100-sheet multipurpose tray, 500-sheet tray 2 for a
total of 600 sheets
100-sheet multipurpose
tray, 500-sheet trays 2,
3, 4 for a total of 1,600
sheets
100-sheet multipurpose
tray, 500-sheet trays 2,
3, 4, 5, 6 for a total of
2,600 sheets
100-sheet multipurpose tray
500-sheet input trays 2, 3, 4 for a total of 1,600 sheets
50-sheet ADF
Two-sided printing Manual Standard automatic two-sided printing
Output 500-sheet face-down output bin 750-sheet stapler/
stacker with job offset
500-sheet face-down output bin 500-sheet
stapler/stacker
700-sheet 3-bin mailbox
Sizes Multipurpose tray: 3 by 5 in (76 by 127 mm) to 8.5 by 14 in (216 by 356 mm); letter, legal, statement,
executive, envelopes (No. 10, commercial); 500-sheet input trays: 5.8 by 8.3 in (148 by 210 mm) to 8.5
by 14 in (216 by 356 mm); letter, legal, executive; custom sizes not supported for automatic two-sided
printing, optional 3-bin mailbox, and stapling with the optional stapler/stacker
Multipurpose tray: 3 by 5 in (76 by 127 mm) to 8.5 by 14 in (216 by 356 mm); letter, legal, executive,
16k, envelopes (No. 10, commercial,); 500-sheet input trays: 5.8 by 8.3 in (148 by 210 mm) to 8.5 by
14 in (216 by 356 mm); letter, legal, executive, custom sizes not supported for automatic two-sided
printing, optional 3-bin mailbox, and stapling with the optional stapler/stacker
Weights Multipurpose tray: 16 to 58 lb bond (60 to 220 g/m 2 ); Automatic two-sided printing, 500-sheet input trays,
optional 3-bin mailbox, stapling with the optional stapler/stacker: 16 to 32 lb bond (60 to 120 g/m 2 )
Multipurpose tray: 16 to 60 lb bond (60 to 220 g/m 2 ); Automatic two-sided printing unit, 500-sheet input
trays, optional 3-bin mailbox, optional stapler/stacker: 16 to 32 lb bond (60 to 120 g/m 2 )
Types Paper (plain, preprinted, letterhead, prepunched, bond, recycled, color, light, intermediate, heavy, extra heavy, rough, glossy, heavy glossy, tough), transparencies, labels, envelopes, card stock
Connectivity
Interfaces Bidirectional IEEE-1284-C parallel port, Hi-Speed USB 2.0 port, two open EIO slots, foreign interface for
third party solutions, Host USB accessory port
Bidirectional IEEE-1284-C parallel port, Hi-Speed USB 2.0 port, one open EIO slot, foreign interface
harness, Host USB accessory port
Network connectivity HP Jetdirect Fast Ethernet embedded print server
Fax interface Not available Optional RJ-11 fax port
Languages HP PCL6, HP PCL5c, HP postscript level 3 emulation, direct PDF printing (v 1.4), PML (Printer Management Language)
Fonts 93 internal TrueType fonts scalable in HP PCL and HP postscript level 3 emulation; additional font solutions
available via flash memory
80 internal TrueType fonts scalable in HP PCL and HP postscript level 3 emulation; additional font solutions
available via flash memory
Client operating systems Windows 98, 2000, Me, XP Home, XP Professional, Server 2003; Mac OS 9.x and higher; Mac OS X
10.1 or higher; optional: OS/2, UNIX®, HP OpenVMS
Windows Vista™ x86, Vista x64, 2000, XP x86, Windows Server 2003 x86, Windows Server 2003
x64, XP x64; Mac OS X v10.2, v10.3, v10.4 or later
Network operating systems 13 Via the HP Jetdirect print server: Windows 98, 2000, Me, XP Home, XP Professional, XP 64-bit, Server
2003; Novell NetWare 3.2, 4.2, 5.x, 6.x (NDPS); Mac OS 8.6 or higher; Red Hat Linux 6.x, 7.x; SuSE
Linux 6.x; HP-UX 10.20, 11.x; Solaris 2.5x, 2.6, 7, 8 (SPARC systems only); IBM AIX 3.2.5 or higher;
MPE-iX; Citrix MetaFrame; Windows Terminal Services; optional: OS/2, UNIX, HP OpenVMS
Microsoft Windows Vista Compatible, Vista Premium, XP, Server 2003, XP, 2003 64-bit, XP 64-bit, 2000
(IPv6 only supported on Windows 2003 and Windows XP; IPsec on IPv4 only on Windows 2003 and
Windows XP); Novell 5.1 and later; Mac OS X v10.2, v10.3, v10.4 or later; Red Hat Linux 7.x and
later; SuSE Linux 8.x and later; HP-UX 10.20, 11.x, 11.i; Solaris 2.5 and later (SPARC systems only); IBM
AIX 3.2.5 and later; MPE-iX; Citrix MetaFrame Server; Windows Terminal Services
Network protocols
supported
13
Via the HP Jetdirect print server: TCP/IP (IP Direct Mode; may require software from the NOS vendor or 3rd
party vendor: LPD, FTP, IPP), IPX/SPX, DLC/LLC, AppleTalk, Auto-IP, Apple Rendezvous compatible, NDS,
Bindery, NCP, Telnet, SLP, IGMP, BOOTP/DHCP, WINS, SNMP v 1, v 2c and v 3, HTTP
IPv6: DHCPv6, HTTP, HTTPS, Port 9100, IP Direct Mode, LPD, IPP, MLDv6, ICMPv6, Apple Bonjour
Compatible, FTP, WS-Discovery; IPv4: FTP, IPP2, Auto-IP, Apple Bonjour Compatible, Telnet, SLP,
IGMPv2, BOOTP/DHCP, WINS, SNMPv1/v2c/v3, TFTP, HTTP, HTTPS, Port 9100, LPD, IP Direct Mode;
Other: IPX/SPX, AppleTalk, NetWare NDS, Bindery, NDPS, iPrint
Dimensions (w by d by h) 20.5 by 23.5 by
22.9 in (521 by 598
by 582 mm)
20.5 by 23.5 by
24.7 in (521 by 598
by 628.6 mm)
24.8 by 28.2 by
39.8 in (630 by 715
by 1010.6 mm)
24.8 by 28.2 by
54.2 in (630 by 715
by 1375.5 mm)
31 by 25.2 by 45.4 in
(788 by 639 by 1153 mm)
43.5 by 25.2 by 45.4 in
(1106 by 639 by 1153 mm)
Weight 105.1 lb (47.7 kg) 107.8 lb (48.9 kg) 230 lb (104.3 kg) 288 lb (130.5 kg) 273 lb (124 kg) 298 lb (136 kg)
What’s in the box Printer, HP Jetdirect Fast Ethernet embedded print server, power cable, software drivers and documentation
on CD, in-box documentation: Getting Started Guide, full-capacity 11,000-page black and 10,000-page
cyan, magenta, and yellow HP Color LaserJet print cartridges 14 with HP ColorSphere Toner, one 100-sheet
multipurpose tray, one 500 sheet input tray
MFP; HP Jetdirect Fast Ethernet embedded print server; power cord; IEEE 1284-C parallel cable; software
drivers and documentation on CD; in-box documentation: Getting Started Guide; full capacity 12,000-page
black, cyan, magenta, and yellow HP Color LaserJet print cartridges 14 with HP ColorSphere toner; 100-
sheet multipurpose tray; 500-sheet input trays 2, 3, 4; 50-sheet ADF
Also includes 4700n plus: Automatic
two-sided printing
accessory
4700dn plus: Printer
stand
4700dtn plus: 40 GB
embedded hard drive,
stapler/stacker with job
offset
CM4730 plus:
HP LaserJet MFP Analog
Fax Accessory 300, phone
cord, Fax Install Guide
CM4730f plus: 500-
sheet stapler/stacker CM4730fsk plus:
700-sheet, 3-bin
mailbox
Environmental ranges
Operating temperature Operating: 50° to 86° F (10° to 30° C); recommended: 62.6° to 77° F (17° to 25° C) Operating: 59° to 86° F (15° to 30° C); recommended: 63° to 77° F (17° to 25° C)
Relative humidity Operating: 10 to 80 %; recommended: 30 to 70 % Operating: 10 to 70 %; recommended: 20 to 60 %
Altitude 0 to 7500 ft (0 to 2300 m) 0 to 8530 ft (0 to 2600 m)
Acoustics
Power Active: 6.7 B(A); Ready: 7.7 B(A) Active: 6.8 B(A), copying; 6.3 B(A), printing; Ready: inaudible
Pressure (bystander) Active: 50 dB(A), standby: 31 d(B)A Active: 52 dB(A), copying; 50 dB(A), printing; Ready: inaudible
Required input voltage 15 110 to 127 V (±10%), 50/60 Hz (±2 Hz); 220 to 240 V (±10%), 50/60 Hz (±2 Hz) 110 to 127 VAC (±10%), 50/60 Hz (±2 Hz)
Power consumption 15
Active, printing 567 watts 591 watts 623 watts 720 watts
Active, scanning 760 watts
Ready 85 watts
Standby 55 watts 63 watts 66 watts
PowerSave 17 watts 18 watts 26 watts
Off 0.3 watts 0.42 watts
Typical Electricity
Consumption (TEC)
6.522kWh/Week
ENERGY STAR ® qualified models; see: http://www.hp.com/go/energystar
7.731 kWh/Week
ENERGY STAR ® qualified models; see: http://www.hp.com/go/energystar
Power certifications
EMC CISPR 22: 1997/EN 55022: 1998 Class B; EN 61000-3-2: 1995/A14; EN 61000-3-3: 1995; EN
55024: 1998; FCC Title 47 CFR, Part 15 Class B/ICES-003, Issue 3/GB9254-1998, GB17625.1-1998;
EMC Directive 89/336/EEC, the Low Voltage Directive 73/23/EEC, and carries the CE-Marking
accordingly
CISPR 22:2005 / EN 55022:2006 Class A, EN 61000-3-2:2000, EN 61000-3-3:1995, EN
55024:1998, FCC Title 47 CFR, Part 15 Class A / ICES-003, Issue 4 / GB9254-1998, GB17625.1-
2003, EMC Directive 89/336/EEC and the Low Voltage Directive 73/23/EEC and carries the CE-
Marking accordingly
Safety Argentina (TUV S Mark-Rs.92/98/Ds.1009/98), Australia (AS/NZ 3260), Canada (cUL-CAN/CSA
C22.2 No.60950-00), Mexico (NOM NYCE-NOM 019 SCFI), USA (UL-UL 60950; FDA-21 CFR Chapter 1
Subchapter J for lasers); Class 1 Laser/LED Product
Canada (cUL-CAN/CSA C22.2 No.60950-1-03), USA (UL-UL 60950-1; FDA-21 CFR Chapter 1
Subchapter J for lasers). Class 1 Laser/LED Product.)
Telecom Not available TBR-21:1998; EG 201 121:1998, FCC Part 68, Industry Canada CS03
Warranty One-year, next day, on-site limited hardware warranty with phone and e-mail support One-year, next day, on-site limited warranty
HP SureSupply™ enabled To learn more about HP SureSupply™, please visit www.hp.com/go/SureSupply
10 Exact speed varies depending on the system configuration, software application, driver, and document complexity.
11 Duty cycle is defined as the maximum number of pages per month of imaged output. This value provides a comparison of product robustness in relation to other HP LaserJet or HP Color LaserJet devices, and enables appropriate deployment of printers and MFPs to satisfy the demands of connected individuals or
groups.
12 HP recommends that the number of printed pages per month be within the stated range for optimum device performance, based on factors including supplies replacement intervals and device life over an extended warranty period.
13 Not all protocol and operating system combinations are supported. For more information, go to: www.hp.com/support/net_printing.
14 All print cartridge page yields are based at five percent page coverage. Declared yield value in accordance with ISO/IEC 19752. For more information, visit www.hp.com/go/pageyield.
15 Values subject to change. See www.hp.com/support/clj4700 or www.hp.com/support/clj4730 for current information. Power reported is the highest value measured using all standard voltages.
