NO. DESCRIPTION PART NO. QTY ITEM NOTE
432A 433A 434A 435A
67 Axle Support 100.000.895 4 3 4 4
67A Axle Support - LH Rear 100.000.896 0 1 0 0
68 Decal - Hayter 410065 1 1 1 1
69 Bracket 432014 1 0 0 0
Bracket 433002W 0 1 1 1
70 Cable - Clutch A/D 434002 0 0 1 1
71 Belt Drive 100.004.594 0 0 1 0
Belt Drive 100.004.919 0 0 0 1
72 Spring - Tension Gearbox 100.000.819 0 0 1 1
73 Gearbox 48 100.004.615 0 0 1 0
Gearbox 53 100.004.816 0 0 0 1
74 Bush - Flanged 100.000.886 0 0 3 3
75 Washer 100.000.634 0 0 2 2
76 Gear Drive Assembly LH 110.002.454 0 0 1 1
77 Gear Drive Assembly RH 110.002.455 0 0 1 1
78 Washer 13mm Dia. 100.000.621 0 0 1 1
79 Setscrew - M6 x 12 09361 0 0 2 2
80 Washer - M6 100.000.965 0 0 2 2
81 Pulley Drive 434001 0 0 1 1
82 Grubscrew - M6 x 10 09769 0 0 1 1
83 Washer 10.5mm Dis 100.000.632 0 1 1 1
84 Rivet - Pop 0.187 Dia MU710259 4 4 4 4
85 Trim - Rear Wheel 200mm 100.033.711 2 2 2 2
86 Washer - 12mm Thin ZPW1L000U 1 1 0 0
1.33
