Page 32
PARTS
LIST
1.32
NO. DESCRIPTION
PART NO.
QTY
ITEM NOTE
432A 433A 434A 435A
40
Bracket - Handlebar LH
110.004.408W
1
0
0
0
Bracket - Handlebar LH
110.004.406W
0
1
1
0
Bracket - Handlebar LH
110.011.753W
0
0
0
1
41
Bracket - Handlebar RH
110.004.409W
1
0
0
0
Bracket - Handlebar RH
110.004.407W
0
1
1
0
Bracket - Handlebar RH
110.011.754W
0
0
0
1
42
Nut - Rivet
100.004.493
4
4
4
4
43
Key
1662
1
1
1
1
44
Clip - Belt Cover
100.000.801
0
2
2
2
45
Cover - Belt
100.000.800
0
1
1
0
Cover - Belt
100.024.883
0
0
0
1
46
Knob - HOC
100.00.828
1
1
1
1
47
Connecting Rod 41
432005W
1
0
0
0
Connecting Rod 48
110.004.415W
0
1
0
0
Connecting Rod 48
434003W
0
0
1
0
Connecting Rod 53
110.032.686W
0
0
0
1
48
Axle - Rear 41
110.033.954W
1
0
0
0
Axle - Rear 48
110.033.881W
0
1
0
0
Axle - Rear 48
110.004.410W
0
0
1
0
Axle - Rear 53
110.033.953W
0
0
0
1
49
Wheel - Rear 200mm
100.000.401
2
2
0
0
Wheel - Rear 200mm
100.000.403
0
0
2
2
50
Nut - M12 Nyloc
100.000.604
4
4
4
4
51
Trim - Front Wheel 180mm
100.033.691
2
2
2
2
52
Wheel - Front 180mm
100.022.836
2
2
2
2
53
Spacer - Axle
100.000.792
4
4
2
2
54
Retainer - Axle
100.000.897
4
4
4
4
55
Screw - Shoulder M6 x 6
100.000.576
2
2
2
2
56
Bolt - UNF 3/8 x 2.25
09122
1
1
1
1
57
Washer - Spring 3/8
09273
1
1
1
1
58
Distance Piece Cutterbar
4014
1
1
1
1
59
Washer - M6
100.000.630
2
2
2
2
60
Ratchet Plate - HOC
110.004.405W
1
1
1
1
61
Axle - Front
110.032.673W
1
0
0
0
Axle - Front
110.004.412W
0
1
1
0
Axle - Front
110.032.682W
0
0
0
1
62
Cutterbar 16”
201026
1
0
0
0
Cutterbar 19”
480149
0
1
1
0
Cutterbar 21”
435005
0
0
0
1
63
Friction Disc
480070W
1
1
0
0
Friction Disc
397042W
0
0
1
1
64
Spacer
321034
1
0
0
0
Spacer ø12 x ø20 x 17
434005
0
1
1
1
65
Deck - Mainframe 41
110.033.852V
1
0
0
0
Deck - Mainframe 48
110.004.382V
0
1
1
0
Deck - Mainframe 53
110.033.553V
0
0
0
1
66
Screw - Taptite 3/8 x 1/4 UNC
09349
3
3
3
3
432011(1) 29/3/04 9:35 am Page 1.32
