Page 31
NO. DESCRIPTION
PART NO.
QTY
ITEM NOTE
432A 433A 434A 435A
1
Decal - Grass Blade
410064
1
1
1
1
2
Engine -
432004
1
1
1
0
Engine
435004
0
0
0
1
3
Decal - Engine
432009
1
0
0
0
Decal - Engine
433009
0
1
1
0
Decal - Engine
435009
0
0
0
1
4
Cable Engine Brake
412007
1
1
1
1
5
Control Throttle
432006
1
1
1
1
6
Knob - Handlebar
480088
2
2
2
2
7
Plug - Handlebar
300160
2
2
2
2
8
Bolt - Saddle
226024
2
2
2
2
9
Nut - Nyloc M6 ‘P’ Type
09544
1
1
1
1
10
Washer - Plain M6.
09472
1
1
1
1
11
Guide - Rope.
305093
1
1
1
1
12
Handlebar - Upper
305145W
1
1
1
1
13
Plug - Drive Large
341033
3
3
3
3
14
Pin - Pivot.
340182
2
2
2
2
15
Lever - Engine Stop.
340179
1
1
1
1
16
Screw - 6 x 20
09687
2
2
2
2
17
Lever - Clutch
306094W
0
0
1
1
18
Fastener - Drive.
300144
4
4
4
4
19
Washer - Nylon.
09688
6
6
2
2
20
Nut - M6 Nyloc ‘T’ Type
09438
3
3
3
3
21
Screw - M6 x 55
09780
1
1
1
1
22
Guide - Cable
410037
2
2
2
2
23
Cable Tie.
3966
1
1
1
1
24
Decal - Rear Deflector
100.031.601
1
1
1
1
25
Handlebar - Lower
432001W
2
2
2
2
26
Screw - M8 x 20
09368
8
8
8
8
27
Nut - M8 Nyloc ‘T’ Type
09441
4
4
4
4
28
Washer - M8
09475
4
4
4
4
29
Decal - Height of Cut.
320006
1
1
1
1
30
Spring - Rear Deflector RH
100.000.826
1
1
1
1
31
Spring - Rear Deflector LH
100.000.825
1
1
1
1
32
Deflector - Rear.
100.000.075
1
0
0
0
Deflector - Rear.
100.000.077
0
1
1
1
33
Frame - Grassbag
432010W
1
0
0
0
Frame - Grassbag
433010W
0
1
1
1
34
Fabric - Grassbag
432003
1
0
0
0
Fabric - Grassbag
433003
0
1
1
1
35
Screw - M5 x 12 Taptite
10-11-029
2
2
2
2
36
Plate - Discharge
110.004.404W
1
1
1
1
37
End Cap - M8 Starlux
100.000.967
2
2
2
2
38
Pin - Deflector
432007
1
0
0
0
Pin - Deflector
433007
0
1
1
1
39
Washer - 5/16
09270
4
4
4
4
LIST
1.31
PARTS
432011(1) 29/3/04 9:35 am Page 1.31
