Parts guide, Part list – Hunter Fan 23483 User Manual
Page 2
Model #
23483
Asm. Dwg. #
95070-01
Finish
White
Item #
Item Name
Qnty
Part #
1
*
Canopy Assembly
239
Hanger Bracket Assembly
1
74090-02
3
Canopy
1
92697-01
7
Hanger Ball / Downrod Assembly
1
74229-24
8
Setscrew
1
03009-01
28
Switch/Housing Assembly
1
96946-03
44
Blade Iron Set
1
93451-05
46
Blade Set
1
74048-19
47
Screw, Blade Iron Armature
11
63755-05
60
*
Hardware Kit
1
95070-00-860
61
62
63
64
65
66
67
68
69
70
71
75
Balancing Kit
1
07570-01
150
Globe/Shade
3
73960-14
Part List
Washer, Installers Choice
Canopy Screw
Screw, Low Profile Washer
Wood Screw
Wood Screw
Blade Grommet
Blade Assembly Screw
Flat Washer
Screw, Machine, 6-32
Wire Connector
Mounting Isolator
R
PARTS GUIDE
PARTS GUIDE
Using the Parts Guide below, check to make sure all parts are included in the box.
98000-01-405
09/21/07
