Top view - fireplace area – Hearth and Home Technologies GRL-700-AU User Manual
Page 4
4
FIGURE 1
FIREPLACE OPENING
Minimum
Maximum
WIDTH:
700mm
1050mm
DEPTH:
300mm
460mm
HEIGHT:
425mm
540mm
DEPTH
WIDTH
TOP VIEW
TOP VIEW - FIREPLACE AREA
GRATE
CONTROL
ACCESS
COVER
PILOT
ASSEMBLY
BURNER
ON/OFF
SWITCH
GAS
VALVE
FLEX TUBE
PIEZO
IGNITOR
FRONT
SUROUND
REAR
SURROUND
300mm
DEPTH
33mm
MINIMUM
NOTE: Unit must
be 33mm back from
fireplace front.
u
