Noise levels
Equivalent (see note 1) noise
pressure level at operator’s
ear, measured according to
relevant international
standards, dB(A).
Equivalent (see note) noise
power level, measured
according to relevant interna-
tional standards, dB(A).
Vibration levels
(See note 2)
Front handle m/s
2
Rear handle m/s 2
Chain/bar
Standard bar length,
inches/cm
Recommended bar lengths,
inches/cm
Usable cutting length
inches/cm
Chain speed at max.
power, m/sec
Pitch, inch/mm
Thickness of drive link,
inch/mm
Number of teeth on drive
sprocket
Engine
Cylinder volume, cu.in/cm 3
Cylinder bore, inch/mm
Stroke, inch/mm
Idle speed, rpm
Recommended max.
speed, unloaded, rpm
Power, kW/rpm
Ignition system
Manufacture
Type of ignition system
Spark plug
Electrode gap, inch/mm
Fuel and lubrication
system
Manufacturer
Carburettor type
Fuel capacity, US pint/litre
Oil pump capacity at 8500 rpm,
ml/min
Oil capacity, US pint/litre
Type of oil pump
Weight
Without bar and chain, Lbs/kg
TECHNICAL DATA
394XP
5,7/94
2,2/56
1,5/38
2.500
12.500
5,2/8.800
SEM
CD
Champion
RCJ 7Y
0.020/0,5
Walbro
WJ 39
1,9/0,9
14-21
0,9/0,5
Automatic
17,4/7,9
Note 1: Equivalent noise level is, according to ISO 7182 and
ISO 9207, calculated as the time-weighted energy total for
noise levels under various working conditions with the following
time distribution: 1/2 idle, 1/2 full load.
Note 2: Equivalent vibration level is, according to ISO 7505,
calculated as the time-weighted energy total for vibration levels
under various working conditions with the following time
distribution: 1/2 idle, 1/2 full load.
394XP
102
111
6,5
10,2
18"/46
18"/46–36"/91
17"/44–35"/88
19,6
3/8 /9,52
0.404"/10,26
0.058/1,5
0.063/1,6
7
Bar and chain combinations
The following combinations are CE approved.
Bar Chain
Length, Pitch, Max.
inches inches number of teeth
nose wheel/radius
nose wheel
18 3/8 34mm Husqvarna H42
20 3/8 34mm Husqvarna H42
24 3/8 34mm Husqvarna H42
28 3/8 34mm Husqvarna H42
24 0.404 34mm Husqvarna H64
28 0.404 34mm Husqvarna H64
32 0.404 42mm Husqvarna H64
36 0.404 42mm Husqvarna H64
18 3/8 11T Husqvarna H42
20 3/8 11T Husqvarna H42
24 3/8 11T Husqvarna H42
28 3/8 11T Husqvarna H42
Type Inch Inch/mm Inch/mm Angle Angle Angle Inch/mm Inch/cm: dl
H42 3/8" 0.058"/1,5 7/32" /5,5 60° 25° 10° 0.025"/0,65 18"/46:68 20"/49:72
24"/61:84 28"/70:92
H64 0.404" 0.063"/1,6 7/32" /5,5 85° 35° 10° 0.030"/0,75 24"/56:76 28"/71:84
32"/81:92 36"/91:104
