HP 1506 - Manual (Page 47)

Technical Specifications
User Guide B–3
1706 Flat Panel Monitor
Display
Type 17.0 inches
TFT LCD 43.18 cm
Viewable Image Size 17.0-inch diagonal 43.18 cm
Tilt --5 to 30
o
Maximum Weight
(Unpacked) 10.1 lbs. 4.60 kg (unpacked)
Dimensions (include pedestal)
Height
Depth
Width
15.6 inches
8.0 inches
14.8 inches 395 mm
203 mm
375 mm
Maximum Graphic Resolution 1280 x 1024 (60 Hz)
Text Mode 720 x 400
Dot Pitch 0.264 (H) x 0.264 (W) mm
Horizontal Frequency 30 to 83 kHz
Vertical Refresh Rate 50 to 76 Hz
Environmental Requirements
Temperature:
Operating Temperature
Non-operating Temperature
41 to 95
o
F
-4 to 140
o
F
5 to 35
o
C
--20 to +60
o
C
Relative Humidity 20 to 80%
Power Source 100 – 240 VAC, 50 – 60 Hz
Altitude:
Operating
Non-operating 0 to 12,000 feet
0 to 40,000 feet 0 to 3657.6 m
0 to12192 m
