Connecting the monitor, Connecting the monitor –3 – HP 1506 User Manual
Page 17
Setting Up the Monitor
User Guide
3–3
Connecting the Monitor
1. Place the monitor in a convenient, well-ventilated location
near your computer.
2. Connect the monitor signal cable on the back of the monitor
to the video connector on the rear panel of the computer.
Å
WARNING: To reduce the risk of electric shock or damage to your
equipment:
■
Do not disable the power cord grounding plug. The grounding
plug is an important safety feature.
■
Plug the power cord into a grounded (earthed) electrical outlet
that is easily accessible at all times.
■
Disconnect power from the monitor by unplugging the power
cord from the electrical outlet.
■
Do not place anything on power cords or cables. Arrange them
so that no one may accidentally step on or trip over them. Do not
pull on a cord or cable. When unplugging from the electrical
outlet, grasp the cord by the plug.
