PARTS GUIDE
PARTS GUIDE
R
98000-01-747
09/10/2007
GUÍA DE PIEZAS
Model # 20345 20347 20349
Asm. Dwg. # 96728-01 96728-02 96728-03
Finish Antique Pewter New Bronze White
Item # Item Name Qnty Part # Part #
* Hanging System Kit 1 96759-14 96759-30 96759-03
2 Ceiling Plate 1 ----------- ----------- -----------
3 Canopy 1 ----------- ----------- -----------
4 Canopy Trim Ring 1 ----------- ----------- -----------
7 Hanger Ball / Downrod Assembly 1 ----------- ----------- -----------
8 Setscrew 1 ----------- ----------- -----------
27 Low Profile Washer 1 ----------- ----------- -----------
62 Canopy Screw 3 ----------- ----------- -----------
64 Wood Screw 2 ----------- ----------- -----------
65 Wood Screw 2 ----------- ----------- -----------
68 Flat Washer 4 ----------- ----------- -----------
100 Locking Screw 3 ----------- ----------- -----------
28 Switch Housing Assembly 1 96730-14 96730-30 96730-03
29 Switch Housing Cover 1 73853-01 73853-01 73853-01
41 Switch Housing Plug Button 1 73854-01 73854-01 73854-01
44 Blade Iron Set 1 92805-05 92805-05 92805-05
46 Blade Set 1 75539-89 75539-90 75885-89
47 Screw, Blade Iron Armature 11 63755-05 63755-05 63755-05
49 Light Kit Assembly 1 96327-01 96327-02 96327-03
* Hardware Kit 1 96728-01-860 96728-01-861 96728-01-861
66 Blade Grommet 16 ----------- ----------- -----------
67 Screw, Blade Assembly 16 ----------- ----------- -----------
69 Screw, Machine, 6-32 3 ----------- ----------- -----------
70 Wire Nut 4 ----------- ----------- -----------
71 Mounting Isolator 4 ----------- ----------- -----------
131 Screw, Switch Housing Assembly 3 ----------- ----------- -----------
75 Balancing Kit 1 07570-01 07570-01 07570-01
86 Remote Control Receiver 1 84368-01 84368-01 84368-01
87 Remote Control Transmitter 1 92754-01 92754-01 92754-01
88 Remote Control Cradle 1 84369-01 84369-01 84369-01
150 Globe / Shade 4 84884-09 84884-09 84884-09
156 Thumb Screw 13 03007-07 03007-07 03007-07
Part List
