Connection Options
The figure is just for reference, please see the real.
And the AC power supply switch is on the back of the set)
DVD
STOP PLAY/PAUSE OPEN/CLOSE
PREV
NEXT
DVD insert
COMPONENT Input
Connect a component
video/audio
device to these jacks
PC Input
Connect to the VGA
15PIN analog output
connector of the PC
display card for PC
display purpose
S-Video Input
Connect S-Video out
from an S-Video device
to the jacks.
Antenna Input
Connect cable or
antenna signals to
the TV, either direc-
tly or through your
cable box.
Earphone port
VGA /COMPONENT/
SVIDEO Audio Input
Connect the PC output
connector from a PC to
the audio input port
SCART
Connect to the DVD/
VCR/broadcasting
receiver or other
equipment
ANT IN
