MIN START
PAUSE
POWER
ON/OFF
Steps of using the operation buttons
and description of the steps
1 Push the POWER ON/OFF button to
switch on the power
2 Push the PROGRAM SELECTION button to
select the suitable automatic program
MIN START
PAUSE
POWER
ON/OFF
b
3 Push WASH RINSE SPIN button to select
suitable programs
After switching on the power,DISINFECT is not selected
To select DISINFECT,push
WATER LEVEL/DISINFECT over 2 seconds,
the DISINFECT function works,then push 2 or 3 to select a suitable program.
POWER
ON/OFF
PROGRAM
1.Lean the machine down gently with the front
surface facing the ground. Loosen the eight
screws by a cross screwdriver.
3. Extend the drain hose from the left side. Push the
drain hose into the groove with hands.
4. Install the bottom plate (as per indicated before),
then lift the machine up gently.
2. Pull out the drain hose from the groove at the
right side.
Back
Front
Bottom plate
Soft item
Use groove at
this side after
direction changing
Push the drain hose
into the groove with
How to change the direction of the drain hose
5 12
Page11
After switching on the power, the machine will set to STANDARD program automatically. To select other
program, push the PROGRAM SELECTION button till the corresponding indicator is on. Refer to the
PROGRAM SELECTION button in Page 11.
For example: select QUICK WASH for the quick washing of
the laundries with light dirt.
SAVE wash
The drainage shall be smooth with the drain hose.
1.put the drain hose up to suitable position (Do not
put it on ground.)
Notes: The highest point of drain pipe shuold be
higher than the water level of washing tub for
avoiding to siphon phenomenon during drain.
2. Do not step on or press the drain hose.
Using the drain hose
0.7m
