H.E.R.O. INDUSTRIES 300S / 300SL LEGEND Owner’s Manual 32
INTAKE PARTS
REF PART # DESCRIPTION QTY
1 4-210 SIPHON ASSEMBLY COMPLETE, ( Ref# 2-7, 48-50 ) ASSY
2 187A SCREEN, Siphon, Coarse, Includes 1
3 Not Used
4 189A-1 TUBE, Siphon, Metal, 5 Gal. 1
5 4-184A HOSE, Siphon, 21”L x 3/4” ID, Lacquer Resistant 1
6 1/75-3 CLAMP 2
7 667-27 BARB, Hose to Elbow, 3/4” 1
8 667-26 ELBOW, 3/4” 1
9 3B CAPSCREW, SKT HD 3/8NC x 2”, Gr. 8 4
10 3-2 WASHER, 3/8" Hi Collar Lock 4
11 4-4B ENDCAP, Includes ref# 12 ASSY
12 6 SEAT, 3/4” Tungsten Carbide 1
13 17S BALL, 3/4”, Steel, Corrosion Resistant,
Use with spring cage ( 4-183S ) 1
14 4-183S CAGE, Spring Loaded, Use with steel ball ( 17S ) 1
15 19A SPRING 1
16 5V O-RING, Viton 1
17 3 CAPSCREW, SKT HD, 5/16 x 1-3/4" 8
18 21E HEAD, Material / Paint 1
19 4-6652 REPAIR KIT ( Ref# 13 (2), 14-16 ) KIT
20 4-6653 OVERHAUL KIT ( Ref# 12, 13 (2), 14-16 ) KIT
OUTGO PARTS
21 7C WASHER, Copper Crush 1
22 4-11A OUTGO VALVE COMPLETE, ( Ref# 23-30) ASSY
23 11A-1 LOWER, Valve Body 1
24 11A-3CP WASHER, Copper Crush 1
25 11A-4 SEAT, 3/8, Tungsten Carbide 1
26 11A-5 BALL, NYLON, 3/8 1
27 11A-6 CAGE 1
28 11A-7 SPRING 1
29 11A-2 UPPER, Valve Body, 1
PARTS LIST
Please order parts by the appropriate part number and not by reference number.
The quantity required, per unit, is shown for each part number. Part numbers in bold text indicate
whole assemblies or kits. These parts may also be purchased individually
