Bird's Eye Instrument View
Bird's Eye Instrument View displays a digital instrument panel next to the
Bird's Eye View. This view provides a digital compass at the top of the view,
as well as 3 selectable readouts to the left of the view.
NOTE: Bird's Eye Instrument View and Chart Instrument View both share the
same set of 3 selectable readouts. When you change the readouts display on one
of these views, you are also changing them on the other view. See Navigation
X-Press™ menu: Select Readouts for more information.
NOTE: If there is only one waypoint in a route, the Next Waypoint and the End
Waypoint info boxes will display the same information, both for that next
waypoint.
Bird's Eye Instrument View
COG: Course Over Ground; the current direction the
boat is traveling measured in degrees from North. Boat Icon 1
SOG: Speed Over Ground; the measurement of the
boat’s progress across a given distance, and is the
speed measurement provided by GPS. 2
Latitude and Longitude Position of Boat 3
4
Land Contours 5
Route 6
1
2
4
5 6
3
21
