Installation and adjustment
4 Push the " water level" button, select suitable water level
After switching on the power, the washing machine will execute fuzzy program automatically to detect the cloth.
After defection, it can set the water level automatically. To select other water level, first push the "start/pause"
button, then push the "water level" button to set the water level.
5 Push the "reserve" button to select suitable reserve wash program
After switching on the power, the reserve program is set to off mode automatically. If you need to
set the washing procedure to be finished at reserved time, please push the " reserve " button to
set the reserve wash program. Refer to reserve button in Page 10 for selection.
Confirm the operation of reserve program
To change the running program or cancel the reserve setting, you
need to switch off the power and make new selection.
6 Push the "Start/Pause" button
6 Finish washing
Water level Water level
After finishing wash it'll
alarm automatically
5 Close the top lid
As the top lid opened, the washer will automatically
given alarm and stop running, exclusively during
draining
The soak procedure can work in cooperation with automatic programs like normal, jeans, fiber and cotton.
There is intermittent pulsator stirring during soak.
After the machine starts operation, you can only set the program and procedure during washing, and can not
make setting in other cases.
Attention
.
Even there's no water in the tub, a certain period is
required before spin starting.
Do not use the soak program for the woolen textiles.
Separate the laundries that are not colorfast from
other laundries in washing.
The pulsator will not rotate unless the water is
filled to"3" water level.
After you open the package, please lean
the washing machine gently down on soft
items ( like the towel cloth, blanket, etc. ).
Install the bottom plate to the bottom of
the machine, then lift the machine up
gently. See to the figure:
Please install and adjust the machine according to the requirement of the manual.
It is very important to your security and correct operating the machine.
Install the bottom plate
Install the Inner cover component
1.Open the top lid of the washing machine.
2.Put the inner cover component on the outer tub cover, aiming
the inner cover shaft to the installation hole of the
corresponding outer tub cover shaft groove.
3.Firstly insert the inner cover shaft of one side into the
corresponding outer tub cover shaft groove, then push
the another inner cover shaft into the corresponding
outer tub cover shaft groove. Please install to designated
position to guarantee there are no dropping or abnormal
sound in opening and closing of the inner cover, and the
operation shall be smooth. Do not dismount the inner cover
component after washing.
Outer tub cover
Outer tub cover shaft groove
Inner cover shaft
Inner cover
Section I enlarging
Damping cushion
Push
Back
Front
Soft items Bottom plate
I
Section I enlarging
Two claws at the bottom cover shall
be inserted in two bar-shaped holes
in the stand. Make sure the claws
are firmly in place.
Before initial use of the machine, assemble the inner cover as described below:
The largest allowable slope of the shank base of the machine is 2 .The slanting or rough ground
will result in unstable running or stoppage of the machine. Please adjust it with following methods:
Confirm it's horizontal:
Hang the lead line to check if it is
horizontal.
Adjust the adjustable leg:
Fasten
Loosen
the adjustable nut
the adjustable feet
High Low
1 .To twist the adjustable leg, please first lift up the
side of the leg slightly, loosen the adjustable nut,
and twist the leg.
2 . After adjustment, fasten the nut.
Adjust the Installation position
