Heatilator • A36C & A42C • 28396 Rev Y • 10/06 47
Service Parts List
Accelerator Woodburning Fireplaces
Service Parts
A36C & A42C SERIES
Beginning Manufacturing Date: N/A
Ending Manufacturing Date: Active
# Description of Part A36C & A36CH A42C & A42CH
Qty.
req.
Refractory Retainer 11847 11847 3
1 Traditional Brick Back Refractory - pre week 34/98 29245 --- 1
Traditional Brick Back Refractory - post wk 34/98 - pre Serial #AK652475 29992 28394 1
Traditional Brick Back Refractory - Textured - post Serial #AK652474 4010-059 4010-060 1
2 Traditional Brick Hearth Refractory - pre week 34/98 29244 --- 1
Traditional Brick Hearth Refractory - post week 34/98 29993 28391 1
Traditional Brick Hearth Refractory 4010-017 4010-018 1
3 Traditional Brick Side Refractory - pre Serial #AK652475 28393 28393 2
Traditional Brick Side Refractory - Textured - post Serial #AK652474 4010-058 4010-058 2
4 Herringbone Brick Back Refractory - pre Serial #AK652475 4010-012 4010-011 1
Herringbone Brick Back Refractory - Textured - post Serial #AK652474 4010-063 4010-064 1
5 Herringbone Brick Hearth Refractory 4010-017 4010-018 1
6 Herringbone Brick RH Refractory - pre Serial #AK652475 4010-009 4010-009 1
Herringbone Brick RH Refractory - Textured - post Serial #AK652474 4010-062 4010-062 1
7 Herringbone Brick LH Refractory - pre Serial #AK652475 4010-010 4010-010 1
Herringbone Brick LH Refractory - Textured - post Serial #AK652474 4010-061 4010-061 1
Herringbone refractory became an option week 3/04.
