Heatilator • A36C & A42C • 28396 Rev Y • 10/06 45
Service Parts List
Accelerator Woodburning Fireplaces
Service Parts
A36C & A42C SERIES
Beginning Manufacturing Date: N/A
Ending Manufacturing Date: Active
# Description of Part A36C A36CH A42C A42CH
Qty.
req.
Firescreen Rod 12052 12052 28404 28404 2
Firescreen Assembly 26053 26053 29246 29246 2
Firescreen Handle 4021-150 4021-150 4021-150 4021-150 1ea.
Upper Door Track 15425 15425 15427 15427 1
Door Pivot Clip 31527 31527 31527 31527 2
1 Starter Section 22069B 22069B 22069B 22069B 1
Damper Assembly 30528 30528 30528 30528 1
Flat Washer 104076 104076 104076 104076 1
Damper Weight 19785A 19785A 19785A 19785A 1
Damper Blade 30558 30558 30558 30558 1
2 Damper Control Arm 14414 14414 14414 14414 1
3 Drywall Flange 29238 29238 28388 28388 1
4 Top Standoff 13433 13433 13433 13433 4
Nailing Flange 31190 31190 31190 31190 4
Strip Protector 18320 18320 18320 18320 2
5 Grate GR18 GR18 GR19 GR19 1
6 Grate Clip 28062 28062 28062 28062 2
7 Hearth Filler 30331 30331 30332 30332 1
Smoke Diverter 30559 30559 1
8 Smoke Shield 31191 31191 35221 35221 1
Right Smoke Baffl e 35329 35329 1
Left Smoke Baffl e 35330 35330 1
9 Lower Grille Assembly 29248 29248 29563 29563 1
10 Upper Grille Assembly 29727 29727 29564 29564 1
Outside Air Kit AK22 AK22 AK22 AK22 1
Junction Box Kit JK9 JK9 JK9 JK9 1
Junction Box 21878 21878 21878 21878 1
Fastener Pack 35063 35063 35063 35063 1
JK9 Installation Instructions 31166 31166 31166 31166 1
Installation Instructions & Owner’s Manual 28396 28396 28396 28396 1
