8 - 4 Rev D
10/18/2007
Dolphin® 7600 User’s Guide
Charging the Main Battery
The HomeBase powers the terminal and fully charges its main battery pack
in less than four hours.
As battery packs charge, the charging circuitry follows the two-step charging
process (CC-CV) that is recommended for Li-Ion batteries. The process
monitors changes in temperature, current, and voltage.
Inserting a Terminal
1. Install the battery pack in the terminal; see Install the Main Battery on
page 2-1.
2. Power the Dolphin HomeBase; see Powering the Dolphin HomeBase
on page 8-3.
3. Slide the terminal into the terminal well until the Dock LED lights green
to indicate that the terminal is properly seated.
4. The battery pack begins charging.
Checking Battery Power
To check battery power while the terminal is operating, tap Start > Settings
> Control Panel > double-tap Power .
