Dolphin® 7600 User’s Guide Rev D
10/18/2007
4 - 1
4
Using the Keyboards
Overview
There are two keyboard options: a 29-key keyboard and the 38-key keyboard.
The buttons are recessed under the overlay for maximum durability and the panel is backlit for maximum viewability in various
lighting conditions.
Suspend/Resume
Both keyboards provide multiple ways to suspend/resume terminal operation.
Suspend Blue + Backlight
Resume Backlight
Scan
SCAN
PG
PG
.
1
ESC
SFT TA B
GHI 4
7 PQRS
B K S P
0 S T A R T
S P
8 TUV
JKL 5
2 ABC
9 WXYZ
6 MNO
DEF 3
29-Key Numeric Keyboard 38-Key Alpha Keyboard
